Network Adapters

With outstanding performance, high power efficiency and excellent value, Supermicro's network adapters can help improve network throughput and application performance through features that maximize bandwidth and offload CPU resources. From 10Gb Ethernet to InfiniBand technologies, dual-port and quad-port connectivity, in UIO (Universal I/O) and standard form factors, Supermicro's network adapters are optimized for the most demanding multi-core computing systems.

		AOC-PTG-i1S  • Proprietary 1U Single-Port 10GbE Ethernet Card • Interface: PCI-E 2.0 x8 • Port: 1x SFP+ port • Speed: 10Gbps • Controller: Intel® 82599EN
		AOC-STG-b4S  • Standard Low-profile 10GbE LAN card • Interface: PCI-E 3.0 x8 (8GT/s) • Port: 4x SPF+ ports • Speed: 10Gbps • Controller: Broadcom® BCM57840S
		AOC-UIBF-m1  • UIO Single-port InfiniBand FDR card • Interface: PCI-E 3.0 x8 (8GT/s) • Port: 1x QSFP connector • Speed: Up to 56Gbps InfiniBand or 40Gbps Ethernet • Controller: Mellanox® ConnectX-3 FDR
		AOC-CTG-i2T  • 2U MicroLP 10 GbE LAN card • Interface: PCI-E 2.1 x8 • Port: 4x RJ-45 ports • Speed: 10Gbps • Controller: Intel® X540
		AOC-CTG-i2S  • MicroLP 10 GbE LAN card • Interface: PCI-E 2.0 x8 (5GT/s) • Port: 2x SFP+ and 2x USB 2.0 ports • Speed: 10Gbps • Controller: Intel® 82599ES
		AOC-CTG-i1S  • MicroLP 10 GbE LAN card • Interface: PCI-E 2.0 x8 (5GT/s) • Port: 1x SFP+ and 2x USB 2.0 ports • Speed: 10Gbps • Controller: Intel® 82599EN
		AOC-CIBQ-m1  • MicroLP InfiniBand QDR card • Interface: PCI-E 3.0 x8 (8GT/s) • Port: 1x QSFP connector + 2x USB 2.0 ports • Speed: Up to 40Gbps InfiniBand or 10Gbps Ethernet • Controller: Mellanox® ConnectX-3 QDR
		AOC-CIBF-m1  • MicroLP InfiniBand FDR card • Interface: PCI-E 3.0 x8 (8GT/s) • Port: 1x QSFP connector + 2x USB 2.0 ports • Speed: Up to 56Gbps InfiniBand or 40Gbps Ethernet • Controller: Mellanox® ConnectX-3 FDR
		AOC-CGP-i2  • MicroLP dual-port GbE LAN card • Interface: PCI-E 2.1 x4 • Port: 2 RJ-45 ports • Speed: 1Gbps per port • Controller: Intel® i350
		AOC-E10GSFPSR • SFP+ Transceiver 1000Base-SX/10GBase-SR plug-in module • Cabling Type: MMF 62.5/50µm • Products Supported: 10Gb Ethernet Controller with SFP+
		AOC-UIBQ-M2 • UIO Low-profile Dual-Port 40Gb InfiniBand card • Interface: PCI-E 2.0 x8 • Port: 2 QSFP ports • Speed: 40Gbps per port • Controller: Mellanox® ConnectX®-2 QDR
		AOC-UIBQ-M1 • UIO Low-profile Single-Port 40Gb InfiniBand card • Interface: PCI-E 2.0 x8 • Port: 1 QSFP port • Speed: 40Gbps per port • Controller: Mellanox® ConnectX®-2 QDR
		AOC-UINF-m2 • UIO Low-profile Dual-Port 20Gb InfiniBand card • Interface: PCI-E 2.0 x8 • Port: 2 CX4 ports • Speed: 20Gbps per port • Controller: Mellanox® ConnectX DDR
		AOC-UTG-i2 • UIO full-height Dual-Port 10Gb Ethernet card • Interface: PCI-E x8 • Port: 2 CX4 ports • Speed: 10Gbps per port • Controller: Intel® 82598EB
		AOC-UG-i4 • UIO full-height Quad-Port 1Gb Ethernet card • Interface: PCI-E x8 • Port: 4 RJ45 ports • Speed: 1Gbps per port • Controller: 2x Intel® 82571EB
		AOC-PG-i2+ • Proprietary low-profile Dual-Port 1Gb Ethernet card • Interface: PCI-E x8 • Port: 2 RJ45 ports • Speed: 1Gbps per port • Controller: Intel® 82576EB
		AOC-EXPX9502FXSR (EOL) • Standard low-profile Dual-Port 10Gb Ethernet card • Interface: PCI-E x8 • Port: 2 XFP ports • Speed: 10Gbps per port • Controller: Intel® 82598EB
